There's a tube of grease on the bench in most shops, and most shops are using too much of it.
It's an easy mistake. Grease is cheap, the O-ring is what keeps the torch sealed, and more protection feels like better protection. So a generous smear goes on, the cap gets threaded down, and everyone gets on with the day.
That grease doesn't stay where you put it.
What actually happens to the excess
The inside of a plasma torch is a gas path. Compressed air or gas moves through it at pressure, every time you strike an arc.
Whatever grease you left sitting proud of the O-ring goes with it.
It clogs swirl rings. The swirl ring's whole job is controlling how gas moves through the torch — that's what gives you a stable arc and a square cut. Its passages are small and precise. Grease finds them, and a partially blocked swirl ring changes your gas flow in ways that look exactly like a dozen other problems.
It gets on the other consumables. Grease where grease shouldn't be, on parts running at temperature, in a gas stream.
It interferes with cooling. An air plasma torch is cooled by the gas flowing through it. Anything that restricts or coats that path is working against the cooling your torch depends on. Run it hot enough for long enough and you're buying parts early — or a torch.
So the excess doesn't just fail to help. It costs you.
The right amount
Use silicone grease.
And use almost none of it.
Just enough to make your fingers shiny. That's it. That's the measure. Put a small amount on your fingertips, wipe it around the O-ring, and if you can see a bead of grease anywhere on the ring, you've used too much and should wipe it back.
No globs. Not in the threads, not packed around the ring, not filling the groove.
You're not sealing with the grease — the O-ring seals. The grease is there so the ring rolls into place instead of pinching or tearing, and so the cap threads down without galling. Both of those jobs need a film, not a coating.
If you're going through a tube of grease at any rate at all, you're using too much. A 25ml tube should last an ordinary shop a very long time.
Silicone grease only
Silicone grease. Nothing else.
Not whatever grease is nearest on the bench, not anti-seize, not oil. Silicone grease, and check your machine manual in case the manufacturer specifies a particular one for your torch — if it does, that's the answer and it beats anything on this page.
When to check them
Start of every shift, and every consumable change.
Not "when something seems off." Before you start, and every time the torch is apart anyway. It's a ten-second look and it's the cheapest inspection in the building.
What you're looking for: cracks, tears, chips. Also flattened, chalky, or taking a permanent set instead of springing back. Any of those and it gets replaced — an O-ring is a few dollars. A leak you chase for a week isn't.
While you're in there
A couple of other things worth doing in the same thirty seconds:
Check whether it's actually seated in its groove, not twisted or pinched on the way in. A twisted O-ring leaks, and it leaks in a way that comes and goes, which is the most annoying kind of fault to chase.
Wipe the parts clean before reassembly. Grease picks up grit, and grit in a gas path is its own problem.
If a torch keeps leaking after a fresh O-ring and correct lubrication, the ring isn't your problem — the torch might be.
The short version
Silicone grease. Fingers shiny. No globs. Wipe the excess.
Everything you leave behind gets blown into the machine, and the machine doesn't want it.
