You've changed the consumables. The air is dry. The plate is flat, the cut still isn't right, and the parts still aren't lasting the way they used to.
Most air plasma problems that show up at the tip started somewhere else on the machine. A handheld or small-table air plasma cutter has five places worth looking, and most shops only ever look at one of them.
Before you touch anything
Switch the machine off. Unplug the power cord. Disconnect the air supply. Every time, before every check in this post.
A plasma cutter carries lethal voltages, and the capacitors inside can hold a charge after the machine is switched off. So there are two kinds of work, and they don't overlap.
Yours: the consumables, the torch, the lead, the air filter, and cleaning out dust with the cover off, using the procedure in your operator manual.
A qualified service technician's: anything electrical inside the cabinet. Boards, connections, components, testing with a meter. If cleaning turns up a burnt smell, a scorched part or a loose wire, put the cover back on and call a tech.
1. The consumables — every shift
Check them at the start of every shift. The electrode and nozzle wear as a pair, so look at them together. The retaining cap should show no burns or cracks, and the swirl ring should have no cracks and no blocked or deformed holes.
We've covered each part and its wear sign in How a Plasma Consumable Stack Works, Part by Part, and what worn parts look like is in How to Tell When Your Air Plasma Consumables Are Worn Out.
Put the stack back together hand tight only. Overtightening the retaining cap squeezes the swirl ring, and a crushed swirl ring changes the gas flow that shapes your arc.
2. The torch body
With the consumables out, look at the torch itself.
- The O-ring. Dry, cracked or torn means it's done. A replacement gets a light coat of silicone grease, just enough to make your fingers shiny. More on that here.
- The body. Cracks or exposed wires mean the torch comes out of service until it's repaired.
- The threads. Damaged threads won't hold the stack in alignment.
- The electrode seat. Look inside where the electrode sits for pitting.
- The vent holes. Slag and debris block them. Clear them with clean, dry compressed air.
- The safety trigger. If it doesn't work properly, don't cut with that torch.
If the torch keeps causing trouble after all of that, it may simply be worn out. Here's how to tell.
3. The torch lead
Run your hand along the lead from the handle to the connector at the machine. Cuts, cracks, crushed sections, melted spots from a hot part landing on it. A damaged lead isn't something to tape up and keep using. Replace it.
While you're there, check the work clamp and its cable. A loose or corroded ground causes problems that look like everything else.
4. The air filter and bowl
This is the one that protects every part listed above.
Take the filter element out and look at it. Dirt, oil or debris on the element means it gets replaced. Wipe any oil or water out of the bowl with a clean, dry rag, and check the O-ring at the top of the bowl for cracks or tears. Your manual shows how the filter and bowl come out on your machine.
If the bowl keeps filling up with water, the filter is doing its job and your air supply is the real problem. Wet air is a consumable killer, and more on air filters here.
5. Inside the machine
An air plasma cutter is air-cooled. It pulls shop air through itself to keep its electronics in their working range, so every bit of grinding dust, mill scale and slag fine in the shop goes through that cabinet too.
That dust does two things. It's conductive, and it chokes the airflow. A machine running hot doesn't always throw a fault. Sometimes it just performs a little worse, in a place nobody thinks to look.
With the machine unplugged and the air disconnected, take the cover off the way your manual describes. Some machines are built with a clean side and a dirty side, and it's the dirty side that collects debris. Vacuum it out first, then blow out what's left with clean, dry compressed air, aimed somewhere safe. Clean only. Don't touch boards or connections. Then put the cover back on before you reconnect anything.
Also look around the machine. Is it sitting where every grinder in the shop points at it? Has someone stacked something against the vents? Clearing that costs nothing.
How often
Two intervals, and that's the whole schedule.
| When | What |
|---|---|
| Start of every shift | consumables and the torch O-ring |
| Every 6 months | torch body, torch lead, air filter and bowl, inside clean |
The short version
| Area | What you're looking for |
|---|---|
| Consumables | worn electrode and nozzle (as a pair), burnt or cracked cap, cracked swirl ring |
| Torch body | dry or torn O-ring, cracks, damaged threads, pitted electrode seat, blocked vents, faulty trigger |
| Torch lead | cuts, cracks, crushed or melted sections, loose ground |
| Air filter | dirt, oil or water on the element or in the bowl, damaged bowl O-ring |
| Inside the machine | dust built up on the dirty side, blocked vents around the cabinet |
